DIGITUS OnLine UPS-modul 2000VA / 2000W

DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
5 668,06 kr
The OnLine UPS is an ideal backup solution for your demanding power requirements and offers high reliability in various industrial applications.- High power factor (1.0), a higher active power enables more connected loads, which saves space and reduces costs.- High efficiency in online mode, higher ... Läs mer
Lager 1 Produktkod 300091 Varumärke DIGITUS Modell DN-170095 Garanti 2 år
KategoriOnline-UPS

Leverans & returer

Beräknad leverans torsdag 5 november
Du får löpande uppdateringar via vårt detaljerade spårningssystem
Betalningsalternativ
BetalkortVisaMastercardPayPalApple PayGoogle PayBanköverföring

The OnLine UPS is an ideal backup solution for your demanding power requirements and offers high reliability in various industrial applications.

- High power factor (1.0), a higher active power enables more connected loads, which saves space and reduces costs.
- High efficiency in online mode, higher efficiency means optimized energy management and lower heat dissipation, resulting in energy savings and improved reliability.
- User-friendly LCD screen provides insight into UPS status for easy installation, configuration and operation.
- Compact rack/tower design optimizes the installation space in the rack and enables flexible installation.
- Minimize device downtime with hot-swappable, user-replaceable battery modules that can be replaced during operation.
- External battery modules allow the runtime to be extended.
- High number of outlets (8 x C13) for optimum power distribution to the consumers.
- Various communication interfaces (RS232/USB, parallel port, SNMP slot) enable remote monitoring of the system.
- Automatic battery self-test and fan speed control increase the service life of the components.
- The REPO function (Remote Emergency Power Off) switches the UPS off in the event of an emergency. If an emergency occurs, the REPO switch turns off the rectifier and the inverter and immediately stops the power supply to the load. The UPS stops charging.

The DIGITUS® OnLine UPS is a double-conversion UPS solution that offers first-class power failure protection and continuous power generation in a compact and flexible system. The single-phase UPS operates with high energy efficiency and is ideal for protecting critical infrastructure in both centralized and edge network applications. Scalable runtime options with matching external battery cabinets provide additional flexibility when a longer uninterruptible power supply is required. The user-friendly LCD display and network management capability, including configuration, make this system easy to install and maintain. With market-leading efficiency and unity power factor, the UPS meets your critical application requirements.

Höjdpunkter
  • Online double conversion system (VFI-SS-111)
  • Input: IEC60320 C20 socket, 208/220/230/240 Vac
  • Output: 8 x IEC60320 C13, max. 10A per socket outlet
  • Nominal system power: 2000 VA / 2000 W, power factor 1.0
  • AC-AC (online VFI) efficiency: 93 %, ECO mode efficiency: 98 %.
  • Internal battery pack can be replaced during operation.
  • Battery: Valve-protected, non-spillable lead-acid battery
  • Battery quantity: 4 x 12V x 9.0 Ah
  • Charging: 4 hours to 90% capacity after full discharge
  • Network connection: Optional SNMP/Webcard (part number DN-170100) enables the UPS to be monitored remotely.
  • Local communication ports: USB, RS-232 (serial), SNMP card (optional), relay card (optional)
  • Emergency Power-off (EPO) contact for switching off the UPS in an emergency
  • Maximum operating temperature: 0 - 40 °C
  • Storage temperature: -25 - 55 °C
  • Relative humidity: 20 - 90% non-condensing
  • Operating altitude: < 1500 m
  • Product dimensions WxDxH (mm): 440 (19") x 460 x 86.5 (2U)
  • Product weight: 19.5 kg
  • Shipping dimensions WxDxH (mm): 560 x 590 x 200
  • Shipping weight: 23.7 kg
  • Safety standards: IEC/EN62040-1,IEC/EN60950-1
  • EMC standards: IEC/EN62040-2,IEC61000-4-2,IEC61000-4-3,IEC61000-4-4, IEC61000-4-5,IEC61000-4-6,IEC61000-4-8
  • Optionally available: 19" UPS mounting kit (profile rails), article number DN-170109
  • IP protection class: IP21
  • Heat dissipation: 614 BTU/h
  • Noise level in online mode: approx. 50 dB(A) at a distance of 1 m (may vary slightly depending on load and ambient temperature).
Specifikationer
Anslutning för nödavstängning (EPO)
Ja
Antal AC-utgångar
8 AC outlet(s)
Antal batterier som stöds
4
Antal seriella portar
1
Avtagbar nätsladd
Ja
Batterikapacitet
9 Ah
Batterispänning
12 V
Bredd
440 mm
Displaytyp
LCD
Djup
460 mm
Drifthöjd
0 - 1500 m
Drifttemperatur (T-T)
0 - 40 °C
Effektfaktor
1
Ethernet LAN-portar (RJ-45)
2
Formfaktor
Rackmonterad
Förpackningens bredd
555 mm
Förpackningens djup
595 mm
Förpackningshöjd
200 mm
Förpackningsvikt
22.9 kg
Förvaringstemperatur (T-T)
-25 - 55 °C
Höjd
86.5 mm
Inbyggd fläkt
Ja
Kylningstyp
Aktiv
Laddningstid batteri (90%)
4 h
Manual
Ja
Max. driftspänning in
240 V
Max. ström
10 A
Medföljande kablar
RS-232, USB cable
Min. driftspänning in
208 V
Nätkontakt
C20 coupler
Paketvolym
66705.5 cm³
Produktfärg
Svart
Rackmonteringssats
Ja
Relativ luftfuktighet vid drift (H-H)
20 - 90%
Relativ luftfuktighet vid förvaring (H-H)
20 - 90%
Seriellt gränssnitt
RS-232
Storlek (tum)
48.3 cm (19")
Typ av strömkälla
AC
Typ av USB-anslutning
USB Type-B
Typer av uttag
C13 coupler
UK-tullkod
85044085
UPS-topologi
Dubbelkonvertering (online)
Ursprungsland
Kina
USB-port
Ja
Utgångseffekt
2000 W
Utgångseffekt
1.5 kVA
Verkningsgrad
93%
Verkningsgrad (ECO-läge)
98%
Vikt
19.5 kg
