Zalman M2 Mini Gray Mini Tower grå

ZALMAN M2 Mini-Gray is a compact Mini-ITX PC case with an aluminium and steel construction and dual-sided acrylic panels. Designed for small form factor builds, the case measures 328(D) x 150(W) x 235(H) mm and supports Mini-ITX motherboards, SFX/SFX-L power supplies and graphics cards up to 295 mm. A pre-installed 80 mm top fan and ventilated acrylic panels provide airflow for efficient cooling.

Advantages

The case combines precision CNC aluminium processing and rounded edges with premium 4T-thick acrylic side panels that protect internal components while allowing airflow through perforations. A smart front I/O offers USB 3.0 and USB 3.1 Gen2 Type-C connectivity plus a power button with LED. A pre-installed PCIe 3.0 riser cable with EMI shielding, 24K-gold plated contacts and a PCB protector supports versatile GPU mounting and reliable signal integrity.

Suitable for

• Compact gaming or productivity Mini-ITX builds
• Small form factor home or office PCs
• SFX or SFX-L power supply installations
• Systems that require a horizontal GPU installation using a riser cable

Key specifications

• Model: M2 Mini-Gray
• Form factor: Mini-ITX
• Dimensions: 328 x 150 x 235 mm (D x W x H)
• Weight: 2.8 kg
• Materials: Aluminium, Steel, Acrylic
• Motherboard support: Mini-ITX
• Maximum VGA length: 295 mm
• Maximum CPU cooler height: 60 mm
• Power supply support: SFX, SFX-L
• PCI expansion slots: 2
• Drive bays: 2 x 2.5" (SSD/HDD)
• Fan support (top): 1 x 80 mm (one 80 mm fan pre-installed)
• I/O ports: 1 x USB 3.0, 1 x USB 3.1 Gen2 Type-C, Power Button (LED)

How to use

Install a Mini-ITX motherboard and an SFX or SFX-L power supply following the case manual. Mount 2.5" drives in the dedicated bays and install a graphics card using the included PCIe 3.0 riser cable and slide-type holding tab for horizontal GPU placement. Connect the front-panel USB ports and power button to the motherboard headers, secure the acrylic side panels with the thumb screws, and route cables to maintain airflow from the top vent and perforated panels.

Recommendations

For optimal cooling, use low-profile CPU coolers no taller than 60 mm, keep the top 80 mm fan clear of obstructions, and choose an SFX or SFX-L power supply that fits the rear/front PSU location. When installing a long GPU, verify compatibility with the 295 mm maximum VGA length and ensure the riser cable is fully seated and the EMI shielding is intact.
