Väggmonterat rack Lanberg WF10-2312-00S

Lanberg's compact 10" wall mounted rack WF10-2312-00S is a 12U cabinet designed for network and low-voltage installations where the combined load does not exceed 20 kg. The grey steel cabinet has an IP20 rating, a glass front door with a lock and up to 180° door rotation. Cable entry is possible through blank panels on the top and bottom. The product ships as a flat pack for self-assembly and includes M6 screws and accessories for wall mounting.

Advantages

The wall mounted rack offers a lightweight but rigid rolled-steel construction and compact dimensions (280 × 310 × 603 mm), making it suitable for installations in limited spaces. Its IP20 protection ensures basic protection against solid objects, while the lockable glass door provides visibility of equipment and physical access control. Flat-pack design simplifies transport and storage, and included mounting hardware speeds up installation.

Suitable for

• Small and medium-sized business network equipment
• CCTV and IP surveillance cameras and recording devices
• Low-voltage systems: access control and alarm installations
• Cable TV and other structured cabling in compact environments

Key specifications

• Model: Lanberg WF10-2312-00S
• Rack capacity: 12U (10" form factor)
• Maximum combined load: 20 kg
• Dimensions (W×D×H): 280 × 310 × 603 mm
• Weight: 8.27 kg
• IP rating: IP20
• Colour: Grey
• Front door: glass, lock included, rotation up to 180°
• Cabling: top and bottom blank entry panels

How to use

Unpack the flat-pack cabinet and follow the included assembly instructions to build the frame and mount the glass front door. Secure the rack to a suitable load-bearing wall using the supplied accessories and M6 screws. Install equipment into the 12U rack space, distribute weight so the combined load does not exceed 20 kg, and route cables through the top or bottom blank entry panels. Lock the front door as needed to restrict physical access.

Recommendations

For safe operation, install the rack on a solid wall able to support the cabinet and mounted equipment, avoid exceeding the 20 kg maximum load, and ensure ventilation around active devices. The IP20 rating protects against solid objects but does not provide protection against water; avoid humid or wet environments.
