Techni-Sat 0010/3144 10dB satellit-inline-förstärkare

Satellite inline amplifier with 10 dB gain, engineered to compensate for signal loss in coaxial cable runs between the LNB or multiswitch and the satellite receiver. Its 950–2150 MHz operating range covers the full satellite IF band, while the 75-ohm impedance and F-type connectors ensure compatibility with standard DVB-S/DVB-S2 installations.

Advantages

The amplifier passes DC power from the receiver to the LNB, so no separate power supply is required. The nickel-plated brass housing provides effective shielding against electromagnetic interference, maintaining signal integrity even in dense RF environments.

Suitable for

• Satellite TV distribution systems with long cable runs
• DVB-S and DVB-S2 receivers requiring signal boost
• Indoor installations or protected outdoor enclosures

Key specifications

• Gain: 10 dB
• Frequency range: 950–2150 MHz
• Impedance: 75 Ohm
• Connectors: F-type female input, F-type male output
• DC pass-through: Yes (12–18 V, <20 mA)
• Housing: Nickel-plated brass

Recommendations

Install the amplifier as close to the LNB or multiswitch as possible for best noise performance. Use high-quality coaxial cable and ensure all connectors are properly tightened to maintain shielding.
