Schemaläggare Logitech Tap 952-000091

The Logitech Tap Scheduler is a purpose-built scheduling panel designed for meeting rooms. Featuring a 10.1" IPS display with 1280 x 800 resolution and PoE power, the compact graphite device provides clear meeting details and room reservation capabilities for ad hoc or planned meetings. It supports Wi‑Fi 802.11ac and 10/100 Mbit/s Ethernet, and includes mounts and cable-routing options for glass, mullion or wall installation.

Advantages

Tap Scheduler offers visible room availability at a distance using colored LED indicators and a spacious, easy-to-read screen. The device is engineered for reliable operation with durable components and a slim, unobtrusive profile. Included mounting accessories and multiple cable management paths enable tidy professional installations in a variety of room types.

Suitable for

• Small meeting rooms and huddle spaces
• Phone booths and individual collaboration areas
• Video conference rooms and shared office spaces
• Reception areas or room corridors for quick room discovery

Key specifications

• Display: 10.1" IPS, 1280 x 800 pixels
• Network: Wi‑Fi 802.11ac; Ethernet 10/100 Mbit/s
• Power: Power over Ethernet (PoE)
• Dimensions: 246.2 mm (W) x 28.5 mm (D) x 165 mm (H)
• Weight: 0.7 kg
• Color: Graphite
• Manufacturer part number (MPN): 952-000091

How to use

Mount the Tap Scheduler using the included glass, mullion or wall mount according to the desired visibility and cable routing. Connect the device to PoE for power and to your network via Ethernet or Wi‑Fi using the supported standards. Integrate the panel with your chosen room-scheduling platform (for example Microsoft Teams or Zoom Rooms) following the provider's setup steps to display meeting details and allow reservations.

Recommendations

For best results, install the Tap Scheduler at eye level near the room entrance and use the provided cable management options to conceal wiring. Monitor and manage the device remotely with Logitech Sync and select the scheduling platform that matches your organization's collaboration tools.
