Hager tehalit mediakopplare vit TR131N

This Hager media coupler provides a flexible, modular solution for integrating multimedia connections into flush-mounted installations. As a 1-module carrier compatible with 45x45 mm inserts, it supports RJ45, F-connector, HDMI, and USB modules, allowing tailored configurations for residential and commercial applications.

Overview

The TR131N is part of the Hager tehalit series, designed for use with tehalit frames and central plates such as Kallysto and Systo. Its white (RAL 9010) thermoplastic housing is halogen-free and UV-resistant, ensuring durability and safety in various environments. The coupler is flush-mounted, maintaining a clean, unobtrusive profile.

What stands out

• Modular design accepts a wide range of multimedia inserts
• Halogen-free, UV-resistant thermoplastic construction
• Impact resistance rated IK05 for robust performance
• Flush-mounted for seamless integration with tehalit frames
• Operating temperature range from -5 to +45 °C

Technical details

• Product type: Media coupler / multimedia module carrier
• Colour: White (RAL 9010)
• Material: Thermoplastic, halogen-free
• Mounting type: Flush-mounted
• Module size: 1-module (45x45 mm standard)
• Compatibility: Hager tehalit frames and central plates (Kallysto, Systo)
• Protection class: IP20
• Operating temperature: -5 to +45 °C
• Storage temperature: -25 to +70 °C
• Relative humidity: 5 to 95 % (non-condensing)
• Impact resistance: IK05
• Series: tehalit
• Number of units: 1

Our verdict

A versatile and reliable media coupler that simplifies multimedia connectivity in flush-mounted installations, backed by Hager's tehalit system compatibility.
