Discovery Artisan 32 digitalmikroskop

The Discovery Artisan 32 is a versatile digital microscope designed for detailed observation and measurement. With a 3-inch color LCD display and a 2MP CMOS sensor, it offers magnifications from 10x to 300x, making it ideal for electronics inspection, hobbyist projects, and educational use. The built-in rechargeable battery provides up to 2.5 hours of cordless operation, while the professional stand with measuring scale ensures stable and precise positioning.

Advantages

This microscope combines optical and digital magnification for clear, detailed images. The adjustable 8-LED illumination ensures optimal lighting in various conditions. It supports image and video capture directly to a MicroSD card, and can be connected to a PC or TV for larger viewing. The included measurement software allows for accurate dimensional analysis.

Suitable for

• Electronics repair and soldering inspection
• Coin, stamp, and jewelry examination
• Biological and botanical studies
• Quality control in manufacturing
• Educational demonstrations

Key specifications

• Magnification: 10–300x (optical 10–200x, digital up to 300x)
• Sensor: 2MP CMOS
• Display: 3-inch color LCD
• Image resolution: up to 1600x1200 pixels
• Video resolution: 640x480 pixels at 30 fps
• Focus range: 0–150 mm (manual)
• Illumination: 8 white LEDs, adjustable
• Power: 5V DC via USB or built-in Li-ion battery (1050 mAh, up to 2.5 hours)
• Storage: MicroSD card up to 32 GB
• Interfaces: USB 2.0, AV output
• Software compatible with Windows 7/8/10/11 and macOS 10.12+
• Includes professional stand with measuring scale

Recommendations

For best results, use a high-contrast background and ensure adequate lighting. The measurement function requires the included software. For extended use, connect to a PC or external monitor.
