Datavideo FS-30

In a live broadcast truck, the Datavideo FS-30 sits between a camera and a vision mixer, locking the incoming SDI signal to the studio reference. It cleans up timing jitter, synchronizes frames, and converts between SD, HD, and 3G formats on the fly, ensuring every source arrives at the switcher in perfect sync and the right resolution.

Key specifications

• 1x 3G/HD/SD-SDI input and 2x 3G/HD/SD-SDI outputs on BNC connectors
• Supports SMPTE 424M (3G-SDI), 292M (HD-SDI), and 259M (SD-SDI) standards
• Built-in frame synchronizer, up/down/cross converter, de-interlacer, and aspect ratio converter
• Handles video formats up to 1080p60, including 1080i, 720p, 576i, and 480i
• Embeds and de-embeds up to 16 channels of 48 kHz, 24-bit audio
• Analog audio I/O via 2x RCA (L/R) in and out; digital audio via 1x AES/EBU BNC (selectable in/out)
• Reference input for black burst or tri-level sync
• Control via DIP switches, USB 2.0, or Ethernet (RJ-45) with on-screen display for setup
• Compact, rugged metal enclosure; DC 12V power, <6W consumption, <1 frame latency

Why choose it

The FS-30 eliminates the need for multiple standalone converters and synchronizers. Its low latency and broadcast-grade processing make it a reliable problem-solver in fast-paced production environments. The metal chassis and simple DIP switch control ensure it can be deployed quickly and stand up to the rigors of the road.

Ideal use cases

• Live event production: synchronize cameras, replay systems, and graphics playout to a common reference
• Broadcast facilities: convert legacy SD sources to HD or 3G for modern infrastructure
• Post-production: ingest mixed-format footage with consistent timing and audio embedding
• Corporate AV: integrate multiple video sources into a single presentation system

Good to know

The FS-30 can be updated via USB, ensuring compatibility with future formats and features. Its on-screen display simplifies configuration without needing a computer, and the Ethernet port allows remote control over a network. With a power draw under 6 watts, it can run for hours on battery power in the field.
